BERCHTOLD professional podiatry nail drill for pedicure work with suction (40,000 rpm) PODO-Q40
Code: 2586-01Price 2490.00 €Aproximate delivery time: 4 - 10 w. d.
0 pcs - Store at Savanoriu av. 49, Vilnius
0 pcs - Vilnius warehouse (1-2 w. d.)
8 pcs - Supplier quantitiesIn stock: 8 pcsLeasing calculators- ml
- esto3
- esto
Brand-
BERCHTOLD PODOQ40 MILLING MACHINE WITH VACUUM PUMP
The Berchtold podoQ40 foot grinder with dust collection is one of the best foot grinders on the market. It is manufactured by the German company BERCHTOLD, which specializes in developing reliable equipment for professional foot clinics.
PodoQ40 is an innovative product with a modern design and exceptional durability.The manufacturer Berchtold provides a 2-year warranty for its equipment (for the handle – 12 months from the date of purchase).
Exceptional quality and comfort
The PodoQ40 is made of the highest quality materials. The color touch screen allows for intuitive control of the device.
The ergonomically shaped handle is particularly light.
To increase the comfort of use, the milling machine has a start/stop button directly on the handle with a dust extraction function.The PodoQ40 is distinguished by its extremely powerful dust extraction and high work efficiency. The device operates much quieter than other routers of similar parameters (noise level: 50-59 dB). The handle is one of the lightest in its class. All these advantages make the Berchtold podoQ40 one of the most attractive choices for professional routers with a dust extraction.
The set includes:
- Berchtold podoQ40 device
- 4 dust bags made of special material
- Power cord
- Instructions for use in Lithuanian
Why is the Berchtold podoQ40 unique?
- High-quality touch screen that informs about the need to replace the dust bag or perform maintenance.
- Ultra-light aluminum handle (~100 g) with brushless motor - one of the lightest on the market.
- Control from the handle – integrated buttons allow you to conveniently adjust the work.
- Brushless dust turbine with 3 suction levels - extremely quiet, barely audible when operating in minimum mode.
- The largest dust bags on the market - special material ensures longer use, and the device itself informs you when they need to be replaced.
- Total weight – only 2300 g, probably the lightest milling machine with a vacuum cleaner on the market.
- Possibility to connect a special lamp, controlled via the touch screen.
- Flexible 130 cm long hose for comfortable working.
- Energy saving, compact dimensions – 300x100x270 mm.
Why choose Berchtold podoQ40?
This device was developed by German engineers in cooperation with podiatrists from all over Europe. As a result, the podoQ40 is characterized by high quality of work, reliability and ease of use. It is made of the highest quality materials, ensuring long-term operation. This is confirmed by a 2-year warranty (12 months for the handle).The aluminum handle with a round suction nozzle effectively collects dust and does not heat up. The ergonomic design allows you to hold it comfortably in your hand, and the low weight reduces the strain on your wrist. In addition, the handle has a quick-release system that allows you to easily change the cutters. Easy maintenance.
Smart features:
PodoQ40 has a system that helps you adjust the speed to the size of the cutter being used – the higher the speed, the smaller the cutter icon on the screen. The device can also emit audible signals to inform you about the selected functions. Three programmable buttons allow you to quickly activate the desired operating modes.Innovative dust bags
The largest dust bags on the market are used, which reduces the frequency of replacement. The display informs you when they need to be replaced - this increases comfort and ensures proper operation of the device.Berchtold podoQ40 – technical characteristics:
- Engine:
- Brushless, long-lasting
- Air flow: 190 l/min
- 3 suction modes
- Working speed: 5000–40000 rpm.
- (factory limit – 25,000 rpm, individual adjustment possible before purchase)
- Handle:
- Length: 135 mm, diameter: 20 mm
- Weight: 100 g
- Aluminum, easy-to-clean, brushless motor
- Noise level: 50-59 dB
- Color: white / dark gray
- Made in: GERMANY
Main unit:
- Dimensions: 300 x 80 x 270 mm
- Weight: 2300g
- Power supply: 95-265V, 50/60Hz
- Hose: 130 cm long
The product is intended only for professional use in beauty cabinets and salons.The device has all the necessary CE certificates that meet the requirements of the Public Health Center.
The device has detailed instructions for use in LT and EN languages.
All device documents are sent to the customer together with the product or to the e-mail specified by the customer after purchasing the product.Product color may slightly vary due to photographic lighting sources or your monitor settings.
WARRANTY TERMS AND MAINTENANCE INSTRUCTIONS FOR MANICURE NAIL DRILLS
First of all, we would like to draw your attention to an important fact: manicure devices, their accessories, dust collectors, LED manicure lamps and other equipment offered for sale cannot be returned or exchanged, as they fall into the category of technically complex products.
Under the law, such products cannot be returned or exchanged simply because you are dissatisfied with their appearance (shape, colour) or have changed your mind.
However, if a nail drill malfunctions, the applicable warranty service conditions apply.Please note: NO replacement device will be provided during repairs.
Warranty terms for electric manicure nail drills:
• All electric manicure nail drills are covered by a 12-month warranty, except for "EXO" nail drill models, which are covered by a 3-month warranty.
• All electric manicure nail drills are intended for commercial use unless otherwise stated.
• Electric nail drill handpieces MUST be maintained and cleaned regularly. Cleaning and regular maintenance of the handpiece are the BUYER'S responsibility.
• When a handpiece is brought to our technicians for cleaning, a standard cleaning fee of EUR 39 applies.Cases not covered by the warranty for electric manicure nail drills:
• Attention! Do not switch between FWD/REV modes without switching off the device's power supply! Failure to follow this rule may cause the device to malfunction. Such damage is not covered by the warranty.
• Bearings and brushes inside the handpiece are replaced for an additional fee, as they are subject to wear and tear. The warranty does not cover components subject to normal wear.
• Failure to comply with the operating conditions of the device resulting in malfunction, including a faulty extension cord to which the device was connected, exceeding the permitted continuous operating time, or using components not included with the device.
• Evidence that the device has been opened or repaired without authorisation, unless such work was previously carried out as part of an authorised warranty repair.
• Mechanical damage caused by careless use or deliberate actions of the user, including liquid spills, dropping the device from a height, or excessive dust and dirt accumulation on the device.
• Damage caused by natural disasters or human-related incidents, including fires, floods, hurricanes and similar events.
• Damage caused by fluctuations in the electrical mains voltage.For example, the instructions specify that the handpiece must be maintained regularly. Therefore, failure to clean the nail drill handpiece regularly may result in a malfunction, and any necessary repairs will be carried out at your expense.
Please note that store managers do not perform fault diagnostics, repairs or other servicing work. The store manager is responsible only for accepting products for warranty repair and communicating with the customer regarding the process. The nature of the malfunction, the repair procedure and other technical matters are determined by a service centre technician.
How should electric manicure nail drills be maintained correctly?
1. First – do not attempt to disassemble the nail drill handpiece motor yourself.
Doing so not only voids the warranty but, more importantly, poses a risk to your safety. There is a relatively powerful spring inside the mechanism. If the motor is disassembled incorrectly, its components may be released at high speed in different directions. This is clearly unsafe.2. Second – what should you do if a new device does not switch on?
2.1. At the factory, switches are often left in an intermediate position. Move each switch back and forth 2–3 times.
2.2. When operating without a foot pedal, check that the HAND/FOOT switch is set to HAND (the factory setting may be FOOT).
2.3. Disconnect and reconnect the handpiece plug, ensuring that it is fully inserted into the device's control unit.
2.4. Gradually increase the rotational speed of the drill bit. Never increase the speed suddenly. Speed adjustments must be made slowly.
2.5. Try connecting the device to a different electrical socket, as the socket currently being used may be faulty.3. Third – some common mistakes when maintaining electric manicure nail drills:
3.1. The handpiece is making a humming noise. Never attempt to repair or clean the handpiece motor yourself (including disassembling it or lubricating the bearings), as this may render the handpiece unusable.
Explanation: The handpiece contains dry friction bearings. These must not be lubricated. If dust has been removed from inside the handpiece but the humming continues, or if the handpiece becomes very hot, the bearings need to be replaced.
Solution: Contact the seller and arrange a handpiece cleaning and bearing replacement service.3.2. The handpiece is heavily contaminated with dust and dirt. Never attempt to wash the handpiece, clean it with wet cloths or immerse it in water.
Explanation: All handpiece components (except the plastic housing) are sensitive to water and moisture. Protect the handpiece from moisture. Do not allow liquids to enter the handpiece, as this may cause irreparable damage. Liquid damage is not covered by the warranty. Compressed inert gas is intended for cleaning the nail drill and can be used without disassembling the handpiece.How should electric manicure nail drills be operated correctly?
Simple rules that will help extend the service life of your electric manicure nail drill:
First – unplug the device from the electrical socket when it is not in use.
This simple rule applies to virtually all electrical appliances. If you are not using the device, unplug it. If the plug remains connected to the socket, the transformer inside the housing may continue to receive power (if you forget to turn off the switch). This shortens its service life.Second – do not operate the handpiece without a drill bit.
Do not switch on the handpiece without an inserted drill bit or the protective shaft supplied with the handpiece. If the handpiece is operated without a bit, the collet mechanism may jam, requiring non-warranty servicing. This creates a load on the rotor, which may fail as a result. In the best-case scenario, the rotor will need to be replaced; in the worst-case scenario, the entire handpiece will need replacement. This is not covered by the warranty.Third – changing the forward/reverse rotation direction.
If you need to change the direction of rotation, gradually reduce the speed to zero (until the drill bit in the handpiece has come to a complete stop), then switch the rotation direction. Reversing the direction before the bit has stopped completely may cause the bit to break or the collet mechanism to jam.Fourth – select the correct drill bit speed.
Exceeding the maximum permitted operating speed of a drill bit may cause the bit to bend, resulting in strong vibration of the handpiece and potentially rendering it inoperable.
This chart applies to all types of nail drill handpiece bits:
Cleaning the nail drill handpiece
Regular cleaning of the nail drill handpiece extends the service life of the device.
There are cases where nail drills used by professionals continue operating for 7–9 years simply because their handpieces are cleaned regularly every month and the bearings are replaced when necessary (approximately every six months).Why is this important? Dust generated during manicure procedures penetrates into the handpiece and clogs its internal mechanisms. This increases wear on moving parts, causes the device to overheat and accelerates bearing wear.
Where can nail drill handpieces be cleaned?
At the seller's service centre or at large certified electrical appliance repair centres.
• Handpiece cleaning at the seller's service centre: up to 14 working days. The device must be delivered to our Vilnius office. You can find the address on our website in the Contact section: https://www.salonams.eu/kontaktai. Price: EUR 39.
• Handpiece cleaning at other certified service centres: please contact the selected service centre for information about service times and prices.
How often should the nail drill handpiece be cleaned?
As always, this depends on individual circumstances, the type of procedures performed and the workload. On average, when a device is used in a salon and the technician serves 4–6 clients per day, the handpiece should be professionally cleaned once every six months and cleaned using compressed inert gas weekly or monthly. If the handpiece starts overheating, vibrating or making unusual noises before six months have passed, professional cleaning should be arranged sooner.Dropping or striking the nail drill handpiece
A strong impact or dropping the handpiece onto a hard floor will almost certainly damage it. In such cases, the handpiece must be taken for non-warranty servicing.
If you have any additional questions or require clarification, please feel free to contact us by email or telephone:
https://www.salonams.eu/en/contacts
Kind regards,
The SALONAMS.EU TeamLove it? Share your thoughts in a review!Write Review -
